Mini android thermal printer high speed printing kiosk panel receipt printer

Shenzhen Masung Technology Co. Ltd
Contact Now

Mini android thermal printer high speed printing kiosk panel receipt printer

Brand Name : MASUNG

Model Number : MS-FPT201/MS-FPT201K

Certification : CE&RHOS

Place of Origin : CHINA

MOQ : 1

Price : USD1~100/piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5,000 units/monthly

Packaging Details : Carton and foam materials

Printing method : Thermal dot line printing

Dot numbers(dots/line) : 384 dots/line

Printing speed(mm/s) : 100 mm/s

Paper width(mm) : 58

Printing width(mm) : 48

Roll diameter max : Φ56 mm

Paper thickness : 60~80 μm

Paper loading method : Easy loading

Auto cutting : YES

Interface : RS-232C

Driver : Windows/Linux/Android OS

Working temperature : -10~60℃

Storage temperature : -20~60℃

Weight : About 0.5KG without paper roll

Contact Now

Mini android thermal printer high speed printing kiosk panel receipt printer

Features:

  1. Brand name printer mechanism
  2. Super big roll bucket diameter Max 56 mm
  3. Compact front panel mounted structure
  4. Unique heat dissipation system
  5. “anti-static” circuit design
  6. Multiple panel LED indication
  7. Available customization shell color
  8. Front paper loading

Specification

Model MS-FPT201

Mechanism

Printing method Thermal dot line
Dot numbers(dots/line) 384 dots/line
Resolution (dots/mm) 8 dot/mm
Printing speed(mm/s) 100 mm/s
Paper width(mm) 58
Printing width(mm) 48
Roll diameter max Φ56 mm
Paper thickness 60~80 μm
Paper loading method Easy loading
Auto cutting YES
sensor Printer head thermistor
Paper end Photo interrupter
Power feature Working voltage(Vp) DC 24V
Power consumption 2A(average)
Peak current 4A
Environment Working temperature -10~60℃
Working humidity 20~85%RH
Storage temperature -20~60℃
Storage humidity 10~90%RH
Reliability Cutter life (cuts) 1,200,000
Pulse 100,000,000
Printing length(km) Over 150
Property Dimension (mm) 101×56×100
Weight (g) 250 ±10
Support Interface RS-232C
Commands ESC/POS
Driver Windows/Linux/Android OS

Application:

Queue management system, visitor attendance terminal, ticket vendor, POS, medical instrument,

gas pump station and more
